Introduction to SmartProfile

Model Number: [ISP]

Click image to enlarge

Course outline:

  • Importing CAD
    • 2D and 3D models
  • Assigning datums
  • Feature creation
    • F.O.S., width, patterns, etc.
  • Assigning geometric tolerances
    • Profile, position, etc.
  • Importing data
  • Analysis
    • Viewing colormaps and "whiskers"
    •  Setting up custom views
  • Reporting
    • Generating 2D reports
    •  Saving SmartProfile projects for 3D viewer

Location:
Productivity Quality Inc.
15150 25th Ave N.  Suite 200
Plymouth, MN  55447

Start/End Time:   12:00PM - 4:00PM

Comments: Seminar includes course materials and certificate of completion.

In 2009, Jordan Pepin joined PQI, parent company of AIS, as a senior applications engineer after working for AIS since May 2004. Along with Jordan's 3 years of experience as an applications engineer working with OGP and BNS machines, Jordan also has a total of over ten years in dimensional metrology and reverse engineering. He is a Senior GD&T Professional certificate holder, and a subject matter expert in the field of GD&T for PQI/AIS.
Price Each: $195.00
